AC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Number of Outputs | Voltage - Input | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Voltage - Output 5 | Voltage - Output 6 | Current - Output 1 | Current - Output 2 | Current - Output 3 | Current - Output 4 | Current - Output 5 | Current - Output 6 | Power (Watts) | Applications | Voltage - Isolation | Operating Temperature | Features | Mounting Type | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EPS-15-48AC/DC CONVERTER 48V 15W |
1,658 |
|
Datasheet |
EPS-15 (15W) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 48V | - | - | - | - | - | 313 mA | - | - | - | - | - | 15W | ITE (Commercial) | 3 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 2.50" L x 1.80" W x 0.94" H (63.5mm x 45.7mm x 24.0mm) |
|
LO15-23B15EAC/DC CONVERTER 15V 15W |
1,940 |
|
Datasheet |
LO15-23BxxE (15W) | Tray | Not For New Designs | Open Frame | 1 | 80 ~ 264 VAC, 88 ~ 430 VDC | 15V | - | - | - | - | - | 1 A | - | - | - | - | - | 15W | ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 3.45" L x 1.97" W x 0.87" H (87.5mm x 50.0mm x 22.0mm) |
|
LO15-23B03EAC/DC CONVERTER 3.3V 9.9W |
2,792 |
|
Datasheet |
LO15-23BxxE (15W) | Tray | Not For New Designs | Open Frame | 1 | 80 ~ 264 VAC, 88 ~ 430 VDC | 3.3V | - | - | - | - | - | 3 A | - | - | - | - | - | 9.9W | ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 3.45" L x 1.97" W x 0.87" H (87.5mm x 50.0mm x 22.0mm) |
|
LO15-23B12EAC/DC CONVERTER 12V 16W |
3,085 |
|
Datasheet |
LO15-23BxxE (15W) | Tray | Not For New Designs | Open Frame | 1 | 80 ~ 264 VAC, 88 ~ 430 VDC | 12V | - | - | - | - | - | 1.3 A | - | - | - | - | - | 16W | ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 3.45" L x 1.97" W x 0.87" H (87.5mm x 50.0mm x 22.0mm) |
|
LO15-23B24EAC/DC CONVERTER 24V 17W |
1,043 |
|
Datasheet |
LO15-23BxxE (15W) | Tray | Not For New Designs | Open Frame | 1 | 80 ~ 264 VAC, 88 ~ 430 VDC | 24V | - | - | - | - | - | 700 mA | - | - | - | - | - | 17W | ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 3.45" L x 1.97" W x 0.87" H (87.5mm x 50.0mm x 22.0mm) |
|
LO45-20B03-MOPEN FRAME AC DC CONVERTERS 26.4 |
3,756 |
|
Datasheet |
LO45-20Bxx-M (45W) | Tray | Not For New Designs | Open Frame | 1 | 85 ~ 264 VAC, 100 ~ 370 VDC | 3.3V | - | - | - | - | - | 8 A | - | - | - | - | - | 26W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.08" H (101.6mm x 50.8mm x 27.5mm) |
|
LO45-20B36-MOPEN FRAME AC DC CONVERTERS 45W |
4,807 |
|
Datasheet |
LO45-20Bxx-M (45W) | Tray | Not For New Designs | Open Frame | 1 | 85 ~ 264 VAC, 100 ~ 370 VDC | 36V | - | - | - | - | - | 1.25 A | - | - | - | - | - | 45W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.08" H (101.6mm x 50.8mm x 27.5mm) |
|
LO45-20B15-MOPEN FRAME AC DC CONVERTERS 45W |
3,767 |
|
Datasheet |
LO45-20Bxx-M (45W) | Tray | Not For New Designs | Open Frame | 1 | 85 ~ 264 VAC, 100 ~ 370 VDC | 15V | - | - | - | - | - | 3 A | - | - | - | - | - | 45W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.08" H (101.6mm x 50.8mm x 27.5mm) |
|
LO45-20B05-MOPEN FRAME AC DC CONVERTERS 40W |
3,415 |
|
Datasheet |
LO45-20Bxx-M (45W) | Tray | Not For New Designs | Open Frame | 1 | 85 ~ 264 VAC, 100 ~ 370 VDC | 5V | - | - | - | - | - | 8 A | - | - | - | - | - | 40W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.08" H (101.6mm x 50.8mm x 27.5mm) |
|
LO45-20B24-MOPEN FRAME AC DC CONVERTERS 45.6 |
1,997 |
|
Datasheet |
LO45-20Bxx-M (45W) | Tray | Not For New Designs | Open Frame | 1 | 85 ~ 264 VAC, 100 ~ 370 VDC | 24V | - | - | - | - | - | 1.9 A | - | - | - | - | - | 46W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.08" H (101.6mm x 50.8mm x 27.5mm) |
|
LO45-20B48-MOPEN FRAME AC DC CONVERTERS 48W |
2,644 |
|
Datasheet |
LO45-20Bxx-M (45W) | Tray | Not For New Designs | Open Frame | 1 | 85 ~ 264 VAC, 100 ~ 370 VDC | 48V | - | - | - | - | - | 1 A | - | - | - | - | - | 48W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.08" H (101.6mm x 50.8mm x 27.5mm) |
|
LO45-20B12-MOPEN FRAME AC DC CONVERTERS 45W |
4,838 |
|
Datasheet |
LO45-20Bxx-M (45W) | Tray | Not For New Designs | Open Frame | 1 | 85 ~ 264 VAC, 100 ~ 370 VDC | 12V | - | - | - | - | - | 3.75 A | - | - | - | - | - | 45W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.08" H (101.6mm x 50.8mm x 27.5mm) |
|
LM35-23B48R2AC/DC CONVERTER 48V 38W |
4,546 |
|
Datasheet |
LM-R2 | Box | Not For New Designs | Enclosed | 1 | 80 ~ 305 VAC, 100 ~ 430 VDC | 48V | - | - | - | - | - | 800 mA | - | - | - | - | - | 38W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, DC Input Capable | Chassis Mount | 3.90" L x 2.56" W x 1.18" H (99.0mm x 65.0mm x 30.0mm) |
|
LM35-23B24R2AC/DC CONVERTER 24V 36W |
4,203 |
|
Datasheet |
LM-R2 | Box | Not For New Designs | Enclosed | 1 | 80 ~ 305 VAC, 100 ~ 430 VDC | 24V | - | - | - | - | - | 1.5 A | - | - | - | - | - | 36W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, DC Input Capable | Chassis Mount | 3.90" L x 2.56" W x 1.18" H (99.0mm x 65.0mm x 30.0mm) |
|
LM35-23B54R2AC/DC CONVERTER 54V 36W |
1,189 |
|
Datasheet |
LM-R2 | Box | Not For New Designs | Enclosed | 1 | 80 ~ 305 VAC, 100 ~ 430 VDC | 54V | - | - | - | - | - | 670 mA | - | - | - | - | - | 36W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, DC Input Capable | Chassis Mount | 3.90" L x 2.56" W x 1.18" H (99.0mm x 65.0mm x 30.0mm) |
|
LM35-23B15R2AC/DC CONVERTER 15V 36W |
4,188 |
|
Datasheet |
LM-R2 | Box | Not For New Designs | Enclosed | 1 | 80 ~ 305 VAC, 100 ~ 430 VDC | 15V | - | - | - | - | - | 2.4 A | - | - | - | - | - | 36W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, DC Input Capable | Chassis Mount | 3.90" L x 2.56" W x 1.18" H (99.0mm x 65.0mm x 30.0mm) |
|
LM50-23B24R2AC/DC CONVERTER 24V 53W |
1,690 |
|
Datasheet |
LM-R2 | Box | Not For New Designs | Enclosed | 1 | 80 ~ 305 VAC, 100 ~ 430 VDC | 24V | - | - | - | - | - | 2.2 A | - | - | - | - | - | 53W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, DC Input Capable | Chassis Mount | 3.90" L x 2.56" W x 1.18" H (99.0mm x 65.0mm x 30.0mm) |
|
LM50-23B05R2AC/DC CONVERTER 5V 50W |
1,660 |
|
Datasheet |
LM-R2 | Box | Not For New Designs | Enclosed | 1 | 80 ~ 305 VAC, 100 ~ 430 VDC | 5V | - | - | - | - | - | 10 A | - | - | - | - | - | 50W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, DC Input Capable | Chassis Mount | 3.90" L x 2.56" W x 1.18" H (99.0mm x 65.0mm x 30.0mm) |
|
LM50-23B36R2AC/DC CONVERTER 36V 52W |
4,460 |
|
Datasheet |
LM-R2 | Box | Not For New Designs | Enclosed | 1 | 80 ~ 305 VAC, 100 ~ 430 VDC | 36V | - | - | - | - | - | 1.45 A | - | - | - | - | - | 52W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, DC Input Capable | Chassis Mount | 3.90" L x 2.56" W x 1.18" H (99.0mm x 65.0mm x 30.0mm) |
|
LM50-23B12R2AC/DC CONVERTER 12V 50W |
4,776 |
|
Datasheet |
LM-R2 | Box | Not For New Designs | Enclosed | 1 | 80 ~ 305 VAC, 100 ~ 430 VDC | 12V | - | - | - | - | - | 4.2 A | - | - | - | - | - | 50W | Household Appliances, ITE (Commercial) | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, DC Input Capable | Chassis Mount | 3.90" L x 2.56" W x 1.18" H (99.0mm x 65.0mm x 30.0mm) |
