AC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Number of Outputs | Voltage - Input | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Voltage - Output 5 | Voltage - Output 6 | Current - Output 1 | Current - Output 2 | Current - Output 3 | Current - Output 4 | Current - Output 5 | Current - Output 6 | Power (Watts) | Applications | Voltage - Isolation | Operating Temperature | Features | Mounting Type | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1010930NXT-400-1004,RE STBY |
3,568 |
|
Datasheet |
NXT-400 (400W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 12V | - | - | - | - | - | 33.3 A | - | - | - | - | - | 400W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 8.00" L x 3.88" W x 1.50" H (203.2mm x 98.5mm x 38.0mm) |
|
|
PET1300-12-054NAAC/DC CONVERTER 12V 1300W |
3,252 |
|
Datasheet |
PET1300 (1300W) | Bulk | Active | Front End | 1 | 90 ~ 264 VAC | 12V | - | - | - | - | - | 108 A | - | - | - | - | - | 1300W | ITE (Commercial) | 4.242 kV | 0°C ~ 60°C | Hot Swappable, I2C Interface, Load Sharing, PFC, PMBus™, Standby Output, Universal Input | Rack Mount | 12.66" L x 2.15" W x 1.57" H (321.5mm x 54.5mm x 40.0mm) |
|
1010945NXT-400-1003,LS-RE |
3,010 |
|
Datasheet |
NXT-400 (400W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 5V | - | - | - | - | - | 80 A | - | - | - | - | - | 400W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 8.00" L x 3.88" W x 1.50" H (203.2mm x 98.5mm x 38.0mm) |
|
1010944NXT-400-1002,LS-RE |
1,125 |
|
Datasheet |
NXT-400 (400W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 3.3V | - | - | - | - | - | 80 A | - | - | - | - | - | 400W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 8.00" L x 3.88" W x 1.50" H (203.2mm x 98.5mm x 38.0mm) |
|
1010947NXT-400-1005,LS-RE |
3,170 |
|
Datasheet |
NXT-400 (400W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 15V | - | - | - | - | - | 26.7 A | - | - | - | - | - | 400W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 8.00" L x 3.88" W x 1.50" H (203.2mm x 98.5mm x 38.0mm) |
|
1010949NXT-400-1007,LS-RE |
4,815 |
|
Datasheet |
NXT-400 (400W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 28V | - | - | - | - | - | 14.3 A | - | - | - | - | - | 400W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 8.00" L x 3.88" W x 1.50" H (203.2mm x 98.5mm x 38.0mm) |
|
ACC750-1T48-PCAC/DC CONVERTER 48V 749W |
4,658 |
|
Datasheet |
ACC750 (750W) | Box | Active | Enclosed | 1 | 85 ~ 305 VAC, 120 ~ 300 VDC | 48V | - | - | - | - | - | 15.6 A | - | - | - | - | - | 749W | ITE (Commercial) | 4 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote On/Off, Remote Sense, Universal Input | Chassis Mount | 9.24" L x 4.00" W x 1.61" H (234.8mm x 101.6mm x 41.0mm) |
|
1011743NXT-400-1006-FN |
1,681 |
|
Datasheet |
NXT-400 (400W) | Box | Active | Enclosed | 1 | 100 ~ 240 VAC | 24V | - | - | - | - | - | 16.7 A | - | - | - | - | - | 400W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 9.40" L x 4.06" W x 1.80" H (238.8mm x 103.1mm x 45.7mm) |
|
PBA600F-7R5AC/DC CONVERTER 7.5V |
3,846 |
|
Datasheet |
PBA (600W) | Box | Active | Enclosed | 1 | 85 ~ 264 VAC | 7.5V | - | - | - | - | - | 80 A | - | - | - | - | - | - | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | - | Chassis Mount | 7.48" L x 4.72" W x 2.40" H (190.0mm x 119.9mm x 61.0mm) |
|
PCA600F-15AC/DC CONVERTER 15V 645W |
4,254 |
|
Datasheet |
PCA (600W) | Box | Active | Enclosed | 1 | 85 ~ 264 VAC, 88 ~ 370 VDC | 15V | - | - | - | - | - | 43 A | - | - | - | - | - | 645W | ITE (Commercial), Medical | 4 kV | -20°C ~ 70°C | Adjustable Output, PFC, Remote On/Off, Remote Sense, Universal Input | Chassis Mount | 5.98" L x 3.50" W x 1.61" H (152.0mm x 89.0mm x 41.0mm) |
|
U7Y0054AC/DC CONVERTER 24V 300W |
1,167 |
|
Datasheet |
CFE400M (400W) | Bulk | Last Time Buy | Open Frame | 1 | 85 ~ 264 VAC | 24V | - | - | - | - | - | 12.5 A | - | - | - | - | - | 300W (400W Forced Air) | ITE (Commercial), Medical | 4 kV | 0°C ~ 60°C (With Derating) | Adjustable Output, Remote On/Off, Standby Output, Universal Input | Chassis Mount | 7.00" L x 3.94" W x 1.57" H (177.8mm x 100.0mm x 40.0mm) |
|
AE-1500-15AC/DC CONVERTER 15V 1500W |
1,191 |
|
Datasheet |
AE-1500 | Box | Active | Enclosed | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 15V | - | - | - | - | - | 100 A | - | - | - | - | - | 1500W | ITE (Commercial) | 3 kV | -25°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Remote On/Off, Remote Sense, Standby Input, Universal Input | Chassis Mount | 11.02" L x 5.00" W x 2.50" H (280.0mm x 127.0mm x 63.5mm) |
|
AE-1500-24AC/DC CONVERTER 24V 1500W |
4,673 |
|
Datasheet |
AE-1500 | Box | Active | Enclosed | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 24V | - | - | - | - | - | 62.5 A | - | - | - | - | - | 1500W | ITE (Commercial) | 3 kV | -25°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Remote On/Off, Remote Sense, Standby Input, Universal Input | Chassis Mount | 11.02" L x 5.00" W x 2.50" H (280.0mm x 127.0mm x 63.5mm) |
|
AE-1500-60AC/DC CONVERTER 60V 1500W |
1,048 |
|
Datasheet |
AE-1500 | Box | Active | Enclosed | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 60V | - | - | - | - | - | 25 A | - | - | - | - | - | 1500W | ITE (Commercial) | 3 kV | -25°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Remote On/Off, Remote Sense, Standby Input, Universal Input | Chassis Mount | 11.02" L x 5.00" W x 2.50" H (280.0mm x 127.0mm x 63.5mm) |
|
PFC250-1015AC/DC CONVERTER 15V 250W |
2,045 |
|
Datasheet |
PFC250 (250W) | Bulk | Active | Enclosed | 1 | 85 ~ 264 VAC | 15V | - | - | - | - | - | 18.3 A | - | - | - | - | - | 250W | ITE (Commercial) | 2.6 kV | 0°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote Sense, Universal Input | Chassis Mount | 8.50" L x 4.75" W x 2.00" H (215.9mm x 120.7mm x 50.8mm) |
|
AHVAC5KV1MABTAC/DC CONVERTER |
4,558 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
PFC250-1024GAC/DC CONVERTER 24V 250W |
4,386 |
|
Datasheet |
PFC250 (250W) | Bulk | Active | Enclosed | 1 | 85 ~ 264 VAC | 24V | - | - | - | - | - | 10.5 A | - | - | - | - | - | 250W | ITE (Commercial) | 2.6 kV | 0°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote Sense, Universal Input | Chassis Mount | 8.50" L x 4.75" W x 2.00" H (215.9mm x 120.7mm x 50.8mm) |
|
MBS601-1T24-SLAC/DC CONVERTER 24V 600W |
2,795 |
|
Datasheet |
MBS601 (600W) | Bulk | Active | Enclosed | 1 | 85 ~ 305 VAC, 170 ~ 300 VDC | 24V | - | - | - | - | - | 25 A | - | - | - | - | - | 600W | Medical | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote On/Off, Remote Sense, Universal Input | Chassis Mount | 9.84" L x 4.92" W x 2.36" H (250.0mm x 125.0mm x 60.0mm) |
|
PBA600F-5-CAC/DC CONVERTER 5V |
1,439 |
|
Datasheet |
PBA (600W) | Box | Active | Enclosed | 1 | 85 ~ 264 VAC | 5V | - | - | - | - | - | 120 A | - | - | - | - | - | - | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | - | Chassis Mount | 7.48" L x 4.72" W x 2.40" H (190.0mm x 119.9mm x 61.0mm) |
|
BAE00FWAC/DC CONVERTER 24V 144W |
4,357 |
|
Datasheet |
- | Bag | Active | Enclosed | 1 | 90 ~ 254 VAC | 24V | - | - | - | - | - | 6 A | - | - | - | - | - | 144W | ITE (Commercial) | 3 kV | -25°C ~ 70°C (With Derating) | Adjustable Output, IP67 | Chassis Mount | 5.47" L x 3.36" W x 2.24" H (139.0mm x 85.4mm x 57.0mm) |
