AC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Number of Outputs | Voltage - Input | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Voltage - Output 5 | Voltage - Output 6 | Current - Output 1 | Current - Output 2 | Current - Output 3 | Current - Output 4 | Current - Output 5 | Current - Output 6 | Power (Watts) | Applications | Voltage - Isolation | Operating Temperature | Features | Mounting Type | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
VMS-450C-27-CFSAC/DC CONVERTER 27V 451W |
4,767 |
|
Datasheet |
VMS-450C-CFS (450W) | Box | Not For New Designs | Enclosed | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 27V | - | - | - | - | - | 16.7 A | - | - | - | - | - | 451W | ITE (Commercial), Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.30" L x 3.39" W x 1.69" H (160.0mm x 86.0mm x 43.0mm) |
|
VMS-450C-15-CFSAC/DC CONVERTER 15V 401W |
4,975 |
|
Datasheet |
VMS-450C-CFS (450W) | Box | Not For New Designs | Enclosed | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 15V | - | - | - | - | - | 26.7 A | - | - | - | - | - | 401W | ITE (Commercial), Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.30" L x 3.39" W x 1.69" H (160.0mm x 86.0mm x 43.0mm) |
|
VMS-450C-36-CFSAC/DC CONVERTER 36V 450W |
1,834 |
|
Datasheet |
VMS-450C-CFS (450W) | Box | Not For New Designs | Enclosed | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 36V | - | - | - | - | - | 12.5 A | - | - | - | - | - | 450W | ITE (Commercial), Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.30" L x 3.39" W x 1.69" H (160.0mm x 86.0mm x 43.0mm) |
|
VMS-450C-24-CFSAC/DC CONVERTER 24V 450W |
4,731 |
|
Datasheet |
VMS-450C-CFS (450W) | Box | Not For New Designs | Enclosed | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 24V | - | - | - | - | - | 18.75 A | - | - | - | - | - | 450W | ITE (Commercial), Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.30" L x 3.39" W x 1.69" H (160.0mm x 86.0mm x 43.0mm) |
|
VMS-450C-48-CFSAC/DC CONVERTER 48V 451W |
4,286 |
|
Datasheet |
VMS-450C-CFS (450W) | Box | Not For New Designs | Enclosed | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 48V | - | - | - | - | - | 9.4 A | - | - | - | - | - | 451W | ITE (Commercial), Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.30" L x 3.39" W x 1.69" H (160.0mm x 86.0mm x 43.0mm) |
|
LFA240F-24-J1AC/DC CONVERTER 24V |
3,039 |
|
Datasheet |
LFA (240W) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC | 24V | - | - | - | - | - | 10 A | - | - | - | - | - | - | ITE (Commercial) | 3 kV | -10°C ~ 70°C | - | Chassis Mount | 5.20" L x 1.97" W x 1.04" H (132.1mm x 50.0mm x 26.4mm) |
|
400158-02-8AC/DC CONVERTER 24V 12V 125W |
4,292 |
|
Datasheet |
XR125 (125W) | Box | Active | Open Frame | 2 | 90 ~ 264 VAC | 24V | 12V | - | - | - | - | 5.2 A | 1 A | - | - | - | - | 125W | ITE (Commercial) | 3 kV | -25°C ~ 70°C | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.12" H (127.0mm x 76.2mm x 28.4mm) |
|
1011374GRN-110-4004 OVP |
4,304 |
|
Datasheet |
GRN-110 (110W) | Box | Active | Open Frame | 4 | 85 ~ 264 VAC | 5V | 24V | 15V | -15V | - | - | 10 A | 2 A | 2 A | 2 A | - | - | 110W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.06" H (127.0mm x 76.2mm x 26.9mm) |
|
LFM300M120CAC-DC SWITCHING POWER MODULE,90- |
2,784 |
|
- |
LFM300M (300W) | Tray | Active | Enclosed | 1 | 85 ~ 264 VAC | 12V | - | - | - | - | - | 25 A | - | - | - | - | - | 160W (300W Forced Air) | Household Appliances, ITE (Commercial), Medical | 4.25 kV | -40°C ~ 80°C (With Derating) | Adjustable Output, PFC, Standby Output, Universal Input | Chassis Mount | 4.09" L x 2.28" W x 1.00" H (103.9mm x 57.9mm x 25.4mm) |
|
LFM300M480CAC-DC SWITCHING POWER MODULE,90- |
4,667 |
|
- |
LFM300M (300W) | Tray | Active | Enclosed | 1 | 85 ~ 264 VAC | 48V | - | - | - | - | - | 6.25 A | - | - | - | - | - | 160W (300W Forced Air) | Household Appliances, ITE (Commercial), Medical | 4.25 kV | -40°C ~ 80°C (With Derating) | Adjustable Output, PFC, Standby Output, Universal Input | Chassis Mount | 4.09" L x 2.28" W x 1.00" H (103.9mm x 57.9mm x 25.4mm) |
|
LFM300M280CAC-DC SWITCHING POWER MODULE,90- |
1,987 |
|
- |
LFM300M (300W) | Tray | Active | Enclosed | 1 | 85 ~ 264 VAC | 28V | - | - | - | - | - | 10.7 A | - | - | - | - | - | 160W (300W Forced Air) | Household Appliances, ITE (Commercial), Medical | 4.25 kV | -40°C ~ 80°C (With Derating) | Adjustable Output, PFC, Standby Output, Universal Input | Chassis Mount | 4.09" L x 2.28" W x 1.00" H (103.9mm x 57.9mm x 25.4mm) |
|
VSUU-120-12AC/DC CONVERTER 12V 120W |
2,931 |
|
Datasheet |
VSUU-120 (120W) | Bulk | Not For New Designs | Open Frame | 1 | 90 ~ 260 VAC, 130 ~ 370 VDC | 12V | - | - | - | - | - | 10.9 A | - | - | - | - | - | 120W | ITE (Commercial) | 4.242 kV | 0°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.54" H (127.0mm x 81.4mm x 39.1mm) |
|
HD240E-124AC/DC CONVERTER 24V 240W |
3,914 |
|
Datasheet |
HD240 (240W) | Box | Active | Enclosed | 1 | 90 ~ 264 VAC | 24V | - | - | - | - | - | 10 A | - | - | - | - | - | 240W | ITE (Commercial) | - | -30°C ~ 80°C (With Derating) | - | Chassis Mount | 4.10" L x 2.46" W x 1.54" H (104.1mm x 62.5mm x 39.1mm) |
|
VMS-550C-36-CNFAC/DC CONVERTER 36V 551W |
3,450 |
|
Datasheet |
VMS-550C-CNF (550W) | Box | Not For New Designs | Enclosed | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 36V | - | - | - | - | - | 15.3 A | - | - | - | - | - | 551W | ITE (Commercial), Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 5.12" L x 3.39" W x 1.69" H (130.0mm x 86.0mm x 43.0mm) |
|
VMS-550C-12-CNFAC/DC CONVERTER 12V 499W |
1,057 |
|
Datasheet |
VMS-550C-CNF (550W) | Box | Not For New Designs | Enclosed | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 12V | - | - | - | - | - | 41.6 A | - | - | - | - | - | 499W | ITE (Commercial), Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 5.12" L x 3.39" W x 1.69" H (130.0mm x 86.0mm x 43.0mm) |
|
MAF300US48B-MU2F4ISOLATED / 300W / VOUT: 48 |
3,796 |
|
Datasheet |
MAF300 (300W) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 48V | - | - | - | - | - | 6.25 A | - | - | - | - | - | 180W (300W Forced Air) | ITE (Commercial), Medical | 4 kV | -40°C ~ 80°C (With Derating) | Adjustable Output, PFC, Universal Input | Chassis Mount | 4.60" L x 2.44" W x 1.56" H (116.8mm x 62.0mm x 39.6mm) |
|
MAF300US24B-MU2F4ISOLATED / 300W / VOUT: 24 |
4,878 |
|
Datasheet |
MAF300 (300W) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 24V | - | - | - | - | - | 12.5 A | - | - | - | - | - | 180W (300W Forced Air) | ITE (Commercial), Medical | 4 kV | -40°C ~ 80°C (With Derating) | Adjustable Output, PFC, Universal Input | Chassis Mount | 4.60" L x 2.44" W x 1.56" H (116.8mm x 62.0mm x 39.6mm) |
|
MAF300US12B-MU2F4ISOLATED / 300W / VOUT: 12 |
2,237 |
|
Datasheet |
MAF300 (300W) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 12V | - | - | - | - | - | 25 A | - | - | - | - | - | 180W (300W Forced Air) | ITE (Commercial), Medical | 4 kV | -40°C ~ 80°C (With Derating) | Adjustable Output, PFC, Universal Input | Chassis Mount | 4.60" L x 2.44" W x 1.56" H (116.8mm x 62.0mm x 39.6mm) |
|
1010972NXT-100-1006 |
1,411 |
|
Datasheet |
NXT-100 (100W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 24V | - | - | - | - | - | 4.2 A | - | - | - | - | - | 100W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 4.50" L x 2.50" W x 1.00" H (114.3mm x 63.5mm x 25.4mm) |
|
1010974NXT-100-1008 |
1,807 |
|
Datasheet |
NXT-100 (100W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 48V | - | - | - | - | - | 2.1 A | - | - | - | - | - | 100W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 4.50" L x 2.50" W x 1.00" H (114.3mm x 63.5mm x 25.4mm) |
