AC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Number of Outputs | Voltage - Input | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Voltage - Output 5 | Voltage - Output 6 | Current - Output 1 | Current - Output 2 | Current - Output 3 | Current - Output 4 | Current - Output 5 | Current - Output 6 | Power (Watts) | Applications | Voltage - Isolation | Operating Temperature | Features | Mounting Type | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
VMS-45-5-CNFAC/DC CONVERTER 2X5V 40W |
3,089 |
|
Datasheet |
Artix® UltraScale+ | Box | Not For New Designs | Enclosed | 2 | 80 ~ 264 VAC, 100 ~ 370 VDC | 5V | 5V | - | - | - | - | 8 A | - | - | - | - | - | 40W | Medical | 4 kV | -40°C ~ 85°C (With Derating) | DC Input Capable, Universal Input | Chassis Mount | 3.00" L x 2.00" W x 1.04" H (76.2mm x 50.8mm x 26.5mm) |
|
Switching Power Supply ALRS12V30ATAC/DC CONVERTER 12V 360W |
1,910 |
|
Datasheet |
- | Bulk | Active | Enclosed | 1 | 90 ~ 264 VAC | 12V | - | - | - | - | - | 30 A | - | - | - | - | - | 360W | ITE (Commercial) | 1.5 kV | -10°C ~ 60°C | Adjustable Output, Universal Input | Chassis Mount | 8.46" L x 4.53" W x 1.97" H (215.0mm x 115.0mm x 50.0mm) |
|
Switching Power Supply ALRS24V15ATAC/DC CONVERTER 24V 360W |
2,599 |
|
Datasheet |
- | Tape & Box (TB) | Active | Enclosed | 1 | 90 ~ 264 VAC | 24V | - | - | - | - | - | 15 A | - | - | - | - | - | 360W | ITE (Commercial) | 1.5 kV | -10°C ~ 60°C | Adjustable Output, IP20, Universal Input | Chassis Mount | 8.46" L x 4.53" W x 1.97" H (215.0mm x 115.0mm x 50.0mm) |
|
VGS-200C-15AC/DC CONVERTER 15V 210W |
2,551 |
|
Datasheet |
VGS-200C (200W) | Box | Not For New Designs | Enclosed | 1 | 90 ~ 264 VAC, 240 ~ 373 VDC | 15V | - | - | - | - | - | 14 A | - | - | - | - | - | 210W | Household Appliances, ITE (Commercial) | 3 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 7.05" L x 3.90" W x 1.18" H (179.0mm x 99.0mm x 30.0mm) |
|
VGS-200C-36AC/DC CONVERTER 36V 212W |
4,990 |
|
Datasheet |
VGS-200C (200W) | Box | Not For New Designs | Enclosed | 1 | 90 ~ 264 VAC, 240 ~ 373 VDC | 36V | - | - | - | - | - | 5.9 A | - | - | - | - | - | 212W | Household Appliances, ITE (Commercial) | 3 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 7.05" L x 3.90" W x 1.18" H (179.0mm x 99.0mm x 30.0mm) |
|
AOJS25-09AC/DC CONVERTER 9V 25W |
2,890 |
|
Datasheet |
AOJS25 (25W) | Bulk | Active | Enclosed | 1 | 88 ~ 264 VAC, 240 ~ 370 VDC | 9V | - | - | - | - | - | 2.8 A | - | - | - | - | - | 25W | ITE (Commercial) | 3 kV | -25°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 3.11" L x 2.01" W x 1.12" H (79.0mm x 51.0mm x 28.5mm) |
|
AOJS25-24AC/DC CONVERTER 24V 26W |
2,502 |
|
Datasheet |
AOJS25 (25W) | Bulk | Active | Enclosed | 1 | 88 ~ 264 VAC, 240 ~ 370 VDC | 24V | - | - | - | - | - | 1.1 A | - | - | - | - | - | 26W | ITE (Commercial) | 3 kV | -25°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 3.11" L x 2.01" W x 1.12" H (79.0mm x 51.0mm x 28.5mm) |
|
LM200-10B15-CAC/DC CONVERTER 15V 210W |
4,382 |
|
Datasheet |
LM200-10Bxx-C (200W) | Box | Not For New Designs | Enclosed | 1 | 90 ~ 132 VAC, 180 ~ 264 VAC, 240 ~ 370 VDC | 15V | - | - | - | - | - | 14 A | - | - | - | - | - | 210W | Household Appliances, ITE (Commercial) | 3 kV | -30°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 7.05" L x 3.90" W x 1.18" H (179.0mm x 99.0mm x 30.0mm) |
|
AD-55BAC/DC CONVERTER 27.6V 26.5V 54W |
4,528 |
|
Datasheet |
AD-55 (55W) | Box | Active | Enclosed | 2 | 88 ~ 264 VAC, 124 ~ 370 VDC | 27.6V | 26.5V | - | - | - | - | 1.8 A | 160 mA | - | - | - | - | 54W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 6.26" L x 3.82" W x 1.50" H (159.0mm x 97.0mm x 38.0mm) |
|
VGS-200C-15-AAC/DC CONVERTER 15V 210W |
1,057 |
|
Datasheet |
VGS-200C (200W) | Box | Not For New Designs | Enclosed | 1 | 90 ~ 264 VAC, 240 ~ 373 VDC | 15V | - | - | - | - | - | 14 A | - | - | - | - | - | 210W | Household Appliances, ITE (Commercial) | 3 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 7.05" L x 3.90" W x 1.18" H (179.0mm x 99.0mm x 30.0mm) |
|
LM350-10B36AC/DC CONVERTER 36V 349W |
4,149 |
|
Datasheet |
LM350-10Bxx (350W) | Box | Not For New Designs | Enclosed | 1 | 90 ~ 132 VAC, 180 ~ 264 VAC, 240 ~ 373 VDC | 36V | - | - | - | - | - | 9.7 A | - | - | - | - | - | 349W | Household Appliances, ITE (Commercial) | 3 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, Standby Output | Chassis Mount | 8.47" L x 4.53" W x 1.18" H (215.0mm x 115.0mm x 30.0mm) |
|
LM350-10B12AC/DC CONVERTER 12V 348W |
1,642 |
|
Datasheet |
LM350-10Bxx (350W) | Box | Not For New Designs | Enclosed | 1 | 90 ~ 132 VAC, 180 ~ 264 VAC, 240 ~ 373 VDC | 12V | - | - | - | - | - | 29 A | - | - | - | - | - | 348W | Household Appliances, ITE (Commercial) | 3 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, Standby Output | Chassis Mount | 8.47" L x 4.53" W x 1.18" H (215.0mm x 115.0mm x 30.0mm) |
|
MAC15US24DISOLATED / 15W / VOUT: 24 |
1,927 |
|
Datasheet |
MAC15 (15W) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 24V | - | - | - | - | - | 625 mA | - | - | - | - | - | 15W | ITE (Commercial), Medical | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 2.61" L x 1.00" W x 0.73" H (66.3mm x 25.4mm x 18.5mm) |
|
LM200-10B36-QAC/DC CONVERTER 36V 212W |
1,425 |
|
Datasheet |
LM200-10Bxx-Q (200W) | Box | Not For New Designs | Enclosed, Conformal Coated | 1 | 90 ~ 132 VAC, 180 ~ 264 VAC, 240 ~ 370 VDC | 36V | - | - | - | - | - | 5.9 A | - | - | - | - | - | 212W | Household Appliances, ITE (Commercial) | 3 kV | -30°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 7.05" L x 3.90" W x 1.18" H (179.0mm x 99.0mm x 30.0mm) |
|
MB60S15CAC/DC CONVERTER 15V 60W |
1,680 |
|
Datasheet |
MB60S (60W) | Box | Active | Open Frame | 1 | 90 ~ 264 VAC | 15V | - | - | - | - | - | 4 A | - | - | - | - | - | 60W | Medical | 4 kV | -10°C ~ 80°C (With Derating) | Universal Input | Chassis Mount | 3.00" L x 2.00" W x 1.00" H (76.2mm x 50.8mm x 25.4mm) |
|
|
LM350-10B15AC/DC CONVERTER 15V 348W |
1,102 |
|
Datasheet |
LM350-10Bxx (350W) | Box | Not For New Designs | Enclosed | 1 | 90 ~ 132 VAC, 180 ~ 264 VAC, 240 ~ 373 VDC | 15V | - | - | - | - | - | 23.2 A | - | - | - | - | - | 348W | Household Appliances, ITE (Commercial) | 3 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, Standby Output | Chassis Mount | 8.47" L x 4.53" W x 1.18" H (215.0mm x 115.0mm x 30.0mm) |
|
LFWLT60-1004AC/DC CONVERTER 48V 65W |
4,237 |
|
Datasheet |
WLT60 (60W) | Bulk | Active | Open Frame | 1 | 90 ~ 264 VAC | 48V | - | - | - | - | - | 1.35 A | - | - | - | - | - | 65W | ITE (Commercial) | 4.242 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.12" H (101.6mm x 50.8mm x 28.5mm) |
|
MAC15US15DISOLATED / 15W / VOUT: 15 |
4,422 |
|
Datasheet |
MAC15 (15W) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 15V | - | - | - | - | - | 1 A | - | - | - | - | - | 15W | ITE (Commercial), Medical | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 2.61" L x 1.00" W x 0.73" H (66.3mm x 25.4mm x 18.5mm) |
|
MAC15US12DISOLATED / 15W / VOUT: 12 |
4,113 |
|
Datasheet |
MAC15 (15W) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 12V | - | - | - | - | - | 1.25 A | - | - | - | - | - | 15W | ITE (Commercial), Medical | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 2.61" L x 1.00" W x 0.73" H (66.3mm x 25.4mm x 18.5mm) |
|
LM200-10B05-QAC/DC CONVERTER 5V 150W |
4,908 |
|
Datasheet |
LM200-10Bxx-Q (200W) | Box | Not For New Designs | Enclosed, Conformal Coated | 1 | 90 ~ 132 VAC, 180 ~ 264 VAC, 240 ~ 370 VDC | 5V | - | - | - | - | - | 30 A | - | - | - | - | - | 150W | Household Appliances, ITE (Commercial) | 3 kV | -30°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 7.05" L x 3.90" W x 1.18" H (179.0mm x 99.0mm x 30.0mm) |
