AC DC Converters
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Number of Outputs | Voltage - Input | Voltage - Output 1 | Voltage - Output 2 | Voltage - Output 3 | Voltage - Output 4 | Voltage - Output 5 | Voltage - Output 6 | Current - Output 1 | Current - Output 2 | Current - Output 3 | Current - Output 4 | Current - Output 5 | Current - Output 6 | Power (Watts) | Applications | Voltage - Isolation | Operating Temperature | Features | Mounting Type | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ZWS240PAF-36AC/DC CONVERTER 36V 240W |
1,137 |
|
Datasheet |
ZWS-PAF (240W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 265 VAC | 36V | - | - | - | - | - | 6.7 A | - | - | - | - | - | 240W | ITE (Commercial) | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 8.74" L x 3.74" W x 1.65" H (222.0mm x 95.0mm x 42.0mm) |
|
|
ZWS240PAF-48AC/DC CONVERTER 48V 240W |
3,926 |
|
Datasheet |
ZWS-PAF (240W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 265 VAC | 48V | - | - | - | - | - | 5 A | - | - | - | - | - | 240W | ITE (Commercial) | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 8.74" L x 3.74" W x 1.65" H (222.0mm x 95.0mm x 42.0mm) |
|
ZWS30-15AC/DC CONVERTER 15V 30W |
3,218 |
|
Datasheet |
ZWS (30W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 265 VAC | 15V | - | - | - | - | - | 2 A | - | - | - | - | - | 30W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 5.24" L x 2.17" W x 1.02" H (133.0mm x 55.1mm x 25.9mm) |
|
|
ZWS30-24AC/DC CONVERTER 24V 30W |
3,313 |
|
Datasheet |
ZWS (30W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 265 VAC | 24V | - | - | - | - | - | 1.3 A | - | - | - | - | - | 30W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 5.24" L x 2.17" W x 1.02" H (133.0mm x 55.1mm x 25.9mm) |
|
|
ZWS30-3AC/DC CONVERTER 3.3V 30W |
1,913 |
|
Datasheet |
ZWS (30W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 265 VAC | 3.3V | - | - | - | - | - | 6.3 A | - | - | - | - | - | 30W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 5.24" L x 2.17" W x 1.02" H (133.0mm x 55.1mm x 25.9mm) |
|
|
ZWS30-36AC/DC CONVERTER 36V 30W |
2,626 |
|
Datasheet |
ZWS (30W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 265 VAC | 36V | - | - | - | - | - | 900 mA | - | - | - | - | - | 30W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 5.24" L x 2.17" W x 1.02" H (133.0mm x 55.1mm x 25.9mm) |
|
ZWS50-12AC/DC CONVERTER 12V 50W |
2,393 |
|
Datasheet |
ZWS (50W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 265 VAC | 12V | - | - | - | - | - | 4.3 A | - | - | - | - | - | 50W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 7.68" L x 2.17" W x 1.02" H (195.0mm x 55.1mm x 25.9mm) |
|
|
ZWS50-15AC/DC CONVERTER 15V 50W |
3,085 |
|
Datasheet |
ZWS (50W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 265 VAC | 15V | - | - | - | - | - | 3.5 A | - | - | - | - | - | 50W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 7.68" L x 2.17" W x 1.02" H (195.0mm x 55.1mm x 25.9mm) |
|
|
ZWS50-24AC/DC CONVERTER 24V 50W |
3,246 |
|
Datasheet |
ZWS (50W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 265 VAC | 24V | - | - | - | - | - | 2.1 A | - | - | - | - | - | 50W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 7.68" L x 2.17" W x 1.02" H (195.0mm x 55.1mm x 25.9mm) |
|
|
ZWS50-5AC/DC CONVERTER 5V 50W |
1,977 |
|
Datasheet |
ZWS (50W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 265 VAC | 5V | - | - | - | - | - | 10 A | - | - | - | - | - | 50W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 7.68" L x 2.17" W x 1.02" H (195.0mm x 55.1mm x 25.9mm) |
|
ZWS5-24AC/DC CONVERTER 24V 5W |
3,149 |
|
Datasheet |
ZWS (5W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 265 VAC | 24V | - | - | - | - | - | 220 mA | - | - | - | - | - | 5W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 3.86" L x 1.77" W x 0.83" H (98.0mm x 44.9mm x 21.0mm) |
|
|
ZWS5-3AC/DC CONVERTER 3.3V 5W |
4,813 |
|
Datasheet |
ZWS (5W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 265 VAC | 3.3V | - | - | - | - | - | 1 A | - | - | - | - | - | 5W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 3.86" L x 1.77" W x 0.83" H (98.0mm x 44.9mm x 21.0mm) |
|
|
ZWS5-5AC/DC CONVERTER 5V 5W |
1,620 |
|
Datasheet |
ZWS (5W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 265 VAC | 5V | - | - | - | - | - | 1 A | - | - | - | - | - | 5W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 3.86" L x 1.77" W x 0.83" H (98.0mm x 44.9mm x 21.0mm) |
|
ZWS75AF-12AC/DC CONVERTER 12V 75W |
4,662 |
|
Datasheet |
ZWS-AF (75W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 265 VAC | 12V | - | - | - | - | - | 6.3 A | - | - | - | - | - | 75W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 8.74" L x 2.17" W x 1.26" H (222.0mm x 55.0mm x 32.0mm) |
|
|
ZWS75AF-24AC/DC CONVERTER 24V 75W |
1,451 |
|
Datasheet |
ZWS-AF (75W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 265 VAC | 24V | - | - | - | - | - | 3.2 A | - | - | - | - | - | 75W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 8.74" L x 2.17" W x 1.26" H (222.0mm x 55.0mm x 32.0mm) |
|
|
ZWS75AF-48AC/DC CONVERTER 48V 75W |
4,269 |
|
Datasheet |
ZWS-AF (75W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 265 VAC | 48V | - | - | - | - | - | 1.6 A | - | - | - | - | - | 75W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 8.74" L x 2.17" W x 1.26" H (222.0mm x 55.0mm x 32.0mm) |
|
|
ZWS75AF-5AC/DC CONVERTER 5V 75W |
3,990 |
|
Datasheet |
ZWS-AF (75W) | Bulk | Obsolete | Open Frame | 1 | 85 ~ 265 VAC | 5V | - | - | - | - | - | 15 A | - | - | - | - | - | 75W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 8.74" L x 2.17" W x 1.26" H (222.0mm x 55.0mm x 32.0mm) |
|
G5-35/OVP-AGAC/DC CONVERTER 5V 175W |
2,146 |
|
Datasheet |
Linear F | Bulk | Obsolete | Linear | 1 | 120VAC | 5V | - | - | - | - | - | 35 A | - | - | - | - | - | 175W | ITE (Commercial) | 3 kV | 0°C ~ 50°C | Adjustable Output, Remote Sense | Chassis Mount | 16.75" L x 4.88" W x 5.00" H (425.5mm x 124.0mm x 127.0mm) |
|
HDBB-105W-AGAC/DC CONVERTER 5V +/-12V 101W |
1,760 |
|
Datasheet |
Linear DBB | Bulk | Obsolete | Linear | 3 | 100, 120, 220, 230, 240 VAC | 5V | 12V | -12V | - | - | - | 12 A | 1.7 A | 1.7 A | - | - | - | 101W | ITE (Commercial) | 3 kV | 0°C ~ 50°C | Adjustable Output, Remote Sense | Chassis Mount | 14.25" L x 4.87" W x 3.38" H (362.0mm x 123.7mm x 85.9mm) |
|
HE48-4-AGAC/DC CONVERTER 48V 192W |
1,363 |
|
Datasheet |
Linear E | Bulk | Obsolete | Linear | 1 | 100, 120, 220, 230, 240 VAC | 48V | - | - | - | - | - | 4 A | - | - | - | - | - | 192W | ITE (Commercial) | 3 kV | 0°C ~ 50°C | Adjustable Output, Remote Sense | Chassis Mount | 14.00" L x 4.87" W x 3.53" H (355.6mm x 123.7mm x 89.7mm) |
